Factory Cat GTX Rider Floor Scrubber (24" Orbital)

New · Factory Cat

Model GTX-24FR · Stock 600V2-24FR

Get a quote Call (262) 333-0799

Factory Cat GTX Rider Floor Scrubber (24" Orbital)
Factory Cat GTX Rider Floor Scrubber (24" Orbital) — photo 1 Factory Cat GTX Rider Floor Scrubber (24" Orbital) — photo 2 Factory Cat GTX Rider Floor Scrubber (24" Orbital) — photo 3 Factory Cat GTX Rider Floor Scrubber (24" Orbital) — photo 4 Factory Cat GTX Rider Floor Scrubber (24" Orbital) — photo 5 Factory Cat GTX Rider Floor Scrubber (24" Orbital) — photo 6 Factory Cat GTX Rider Floor Scrubber (24" Orbital) — photo 7 Factory Cat GTX Rider Floor Scrubber (24" Orbital) — photo 8

Description

The Factory Cat GTX is Factory Cat’s mid-size rider, and this 24” orbital version puts a rectangular orbital pad under a seated operator for chemical-free finish removal on a six-hour shift. Best for: large spaces from about 30,000 to 80,000 sq ft: schools, hospitals, and office campuses where finish gets stripped without fumes and corners matter. Smooth hard floors such as VCT, terrazzo, and sealed concrete.

  • 24” orbital deck, 1 hp, up to 200 lb down pressure
  • Chemical-free finish removal, no swirl marks
  • 33 gal solution / 36 gal recovery tanks, up to 6 hours per charge
  • 47,000 sq ft/hr theoretical coverage, 825 to 875 lb operating weight

Standard build includes six 6 V / 210 Ah wet batteries (36 V system), an onboard 36 V / 25 A charger, and the patented service cabinet.

Specifications

TypeRider
Cleaning path24"
BrushOrbital
Power36 V battery (210 Ah, wet)
Run timeup to 6 hr
Tanks (solution / recovery)33 / 36 gal
Productivity47,000 sq ft/hr
DriveTraction drive
Brush pressureup to 200 lb
Brush speed2,500 rpm
Weight825–875 lb
What's included
  • Choice of controller and scrub brush
  • All steel 1/8" and 3/16" / 3.1 and 4.8 mm / 7 ga powder coated frame supports weight of machine
  • 33 gal / 125 L poly solution tank with "Site Tube" level gauge and integrated drain hose
  • 36 gal / 136 L poly recovery tank with 1.5" / 3.8 cm diameter drain hose with flow control
  • Orbital deck: 1.0 HP / 2700 RPM, blue pad
  • Patented vacuum box for noise reduction and vacuum protection
  • Patented service cabinet
  • (6) 6 V / 210 Ah wet batteries — 36 V system
  • Onboard 36 V / 25 A charger
  • Drain Saver system
  • Stainless fasteners
  • 33" squeegee
Available options

Controller

  • Red Military Grade Controller
  • Black Legacy Trio LCD Controller
  • Touch Screen Controller, 4" Display

Batteries — lead acid (wet)

  • Battery Upgrade WET 240ah
  • Battery Upgrade WET 310ah
  • Battery Upgrade WET 360ah

Batteries — AGM (maintenance-free)

  • Battery Upgrade 224ah AGM
  • Battery Upgrade AGM 335ah

Batteries — lithium

  • 180ah Lithium Battery Package (Qty 4) + Onboard Charger 36V/33A(Requires Custom Program Charger + Controller)
  • 270ah Lithium Battery Package (Qty 6) + Onboard Charger 36V/33A(Requires Custom Program Charger + Controller)

Chargers

  • Charger Upgrade, Onboard, WET, 36V/33A
  • Charger Upgrade, Onboard, AGM, 36V/33A

Battery and charger accessories

  • Single Point Watering System w/ Indicator Light Hand Pump

Tank configuration

  • Spec Ops Package

Cleaning, sanitizing and disinfecting

  • O3+ Package: Aqueous Ozone & Chemical Dilution
  • Suds Onboard Chemical Dilutionwith case of soap samples
  • ZerO3 Onboard Aqueous Ozone Package

Cleaning, sanitizing and disinfecting accessories

  • Rear Spray Bar w/ handheld Spray Gundrawn from Solution Tank
  • Blue Garden Hose w/ Spray Nozzle, 45PSI
  • Vacuum Wand
  • Off Aisle Vacuum Wand & Spray Jet - 45 psi/ 3gpm
  • Green High-Pressure Hose, Spray Gun w/3 Tips, 100PSI
  • Tanks,Green,Antimicrobial

Wheels, tires and casters

  • All Tires Swap, Solid Grey Non-Marking
  • P7,Front Drive Swap,Imperial Drive

Electrical

  • Blue Safety Light - Front & Rear Facing
  • Strobe Light - Amber
  • Dual Headlights & Dual Rear Worklights
  • Freezer Package
  • Low Solution / High Recovery Alert System
  • Dual Manager Lock Out - Solution & Pressure- Legacy Trio Only

Other options

  • Drain Hose Extension, 15' 1.5" Diameter Hose
  • Squeegee Hose with Coiled Trap at End
  • Seat Belt
  • Raised Operator Floor Plate
  • Color Swap - Red to Granite

Side broom systems (factory installed)

  • Side Broom System w/ Broom Guards

Heavy duty

  • Side Doors for 26" Disk, 28" Disk,25" Cylindrical & 24" Orbital
  • Mainframe Undercoating
  • Brass Cylindrical Idler & Driver Upgrade
  • Overhead Guard
  • Metal Recovery Lid

Hopper

  • Hopper Screen

Squeegee size

  • 33" v2.1HD Squeegee - Standard on 26D, 25C & 24R

Options are factory-installed at order time. Ask for a quote with the options you want.
