Kodiak K22R Micro Rider Floor Scrubber (24" Orbital)

New · Kodiak

Model K22-24FR · Stock K22-24FR

$13,358

Get a quote Call (262) 333-0799

Kodiak K22R Micro Rider Floor Scrubber (24" Orbital)
Kodiak K22R Micro Rider Floor Scrubber (24" Orbital) — photo 1 Kodiak K22R Micro Rider Floor Scrubber (24" Orbital) — photo 2

Description

The Kodiak K22R 24” orbital puts a rectangular orbital pad on Kodiak’s micro rider, for chemical-free finish removal by one seated operator. Best for: mid-size spaces from about 15,000 to 50,000 sq ft: schools, hospitals, and clean facilities where stripper fumes are not an option. Smooth hard floors such as VCT, terrazzo, and sealed concrete.

  • 24” orbital deck, 1.5 hp motor at 2,500 rpm pad speed
  • Chemical-free finish removal, no swirl marks
  • Front-wheel drive and steer, operator seated and facing forward
  • 22 gal solution / 23 gal recovery tanks, up to 4 hours per charge
  • 31,135 sq ft/hr theoretical coverage; ECO mode and three automatic pressure and flow settings

Standard build includes two 12 V / 130 Ah wet batteries (24 V system), an onboard 24 V / 12 A charger, an all-steel frame, and a curved squeegee.

Specifications

TypeRider
Cleaning path24"
BrushOrbital
Power24 V battery (130 Ah, wet)
Run timeup to 4 hr
Tanks (solution / recovery)22 / 23 gal
Productivity31,135 sq ft/hr
What's included
  • Orbital deck: Blue pad – single 1.5 HP / 2500 RPM pad speed
  • All steel 3/16" / 4.7 mm / 7 ga powder coated frame supports weight of machine
  • 22 gal / 83 L poly solution tank and 23 gal / 87 L poly recovery tank
  • (2) 12 V / 130 Ah wet batteries — 24 V system
  • Onboard 24 V / 12 A charger
  • Curved squeegee with tool-less blade adjustment
  • Deluxe controller 3 auto settings scrub pressure and water flow
  • 3 hour meters and detailed fault codes for troubleshooting
  • ECO mode for quiet operations and energy conservation
  • Front wheel drive-steer / black rear tires
  • 31" squeegee
Available options

Batteries and chargers

  • 130ah WET (2x) / Onboard CE & CEC 12Aincluded
  • 150ah WET (2x) / Onboard CE & CEC 12A$129
  • 240ah WET (4x) / Onboard CE & CEC 27A$428
  • 150ah AGM (2x) / Onboard CE & CEC 12A$325
  • 224ah AGM (4x) / Onboard Charger & CEC 27A$708
  • 90ah Lithium / Onboard CE & CEC 27A$2,791
  • 180ah Lithium (2x90ah) / Onboard CE & CEC 27A$5,926
  • 270ah Lithium (3x90ah) / Onboard CE & CEC 27A$9,061
  • Onboard CE & CEC 27A / No Batteries$133

Battery and charger accessories

  • Single Point Watering System w/ Indicator Light$423

Cleaning and disinfecting

  • Green High-Pressure Hose, Spray Gun w/3 Tips, 100PSI, w/ Dedicated 2 gal Tank$947
  • Blue Garden Hose w/ Spray Nozzle, 45PSI, Plumbed into solution tank$731
  • ZerO3 Onboard Aqueous Ozone Package$1,548
  • Green High-Pressure Hose, Spray Gun w/3 Tips, 100PSI  Plumbed into solution tank$1,000

Cleaning and disinfecting accessories

  • Vacuum Wand$328

Electrical

  • Dual Headlights$362
  • Strobe Light$203
  • Blue Safety Light - Front & Rear Facing$1,295
  • High-Performance Vac Motor$158
  • Low Solution / High Recovery Alert System$418

Tires

  • Black Rear Tiresincluded
  • Grey Non-Marking Rear Tires$129

Squeegees

  • 28" Squeegeeincluded
  • 31" Squeegeeincluded
  • 33" Squeegeeincluded
  • 37" Squeegee$190

Controller

  • 24v - 3” Color LCD Orio DES (70a)included
  • Touch Screen Controller$212

Options are factory-installed at order time. Ask for a quote with the options you want.
